MC9400/MC9450 Ultra-Rugged Mobile Computer
Models
MC9400, MC9450
The Next Evolution in the Ultra-Rugged MC9000 Series. Now with More Power and Wireless Connectivity
The MC9400/MC9450 provides the latest mobile technologies. Faster, ready to power the new generation of industrial applications and with the SE58 Extended Range Scan Engine with IntelliFocus™ that delivers an unprecedented extended scanning range. Upgrade to the latest productivity-enhancing mobility features with full backwards compatibility with the MC9300 accessories. Wi-Fi 6E and private and public 5G (data only) to meet your needs and get the fastest wireless connections available today.
Description
Specifications
Physical Characteristics
| Dimensions
|
9.4 in. L x 3.5 in. W x 7.4 in. H 240 mm L x 88 mm W x 189 mm H |
| Weight | 26.2 oz./743 g with battery |
| Display | 4.3 in. WVGA (800 x 480), color display, 600 NITS (typical) |
| Imager Window | Corning™ Gorilla™ Glass |
| Touch Panel | Dual mode capacitive touch with finger, gloved finger or stylus input (conductive stylus sold separately); screen protector (sold separately); Corning Gorilla Glass with air gap (standard model) or optically bonded (freezer model) |
| Power | Rechargeable Li-Ion: 3.6V, 7000mAh (25.20 Wh); Optional BLE Battery Li-Ion 3.6V, 7000mAh (25.20 Wh); Optional Freezer Capacity battery — 5000mAh (18.80 Wh); Optional 7000mAh (25.20 Wh) Non-Incendive battery; Hot swap battery backup with temporary session persistence |
| Expansion Slot | MicroSD supports up to 2 TB |
| SIM | MC9450 only: 1 nano SIM; 1 eSIM |
| Network Connections | MC9400/MC9450: WLAN, WPAN (Bluetooth), USB 2.0, High Speed (host and client); MC9450 only: WWAN 5G; data only |
| Notifications | Audible tone; multi-color LED; haptic feedback |
| Keypad | Backlit, field replaceable keypads; 58 Key AlphaNumeric, 53 Key AlphaNumeric STD, 53 Key Terminal Emulation (5250 and VT), 43 Key/34 Key Numeric/Function, 29 Key Numeric/Calculation |
| Voice and Audio | Speaker, microphone, PTT voice (internal speaker and Bluetooth wireless headset support) |
| Buttons | Trigger scan button; keypad scan button |
| Interface Ports | USB 2.0 (bottom pogo connector) — high speed (host and client) |
Performance Characteristics
| CPU | Qualcomm 4490 octa-core; 2.4 GHz |
| Operating System | Android; for supported Android versions |
| Memory | 6 GB RAM/128 GB Flash |
| Security | FIPS 140-2 Validated; supports Secure Boot and Verified Boot |
User Environment
| Operating Temperature | Standard: -4°F to 122°F/-20°C to +50°C, Freezer: -22°F to 122°F/-30°C to +50°C |
| Storage Temperature | -40°F to 158°F/-40°C to 70°C |
| Humidity | Standard: 5%-95% non-condensing; Freezer: 5%-95% condensing (condensation resistant model with heaters for scanner exit window and touch panel glass) |
| Drop Specification | Exceeds per MIL-STD-810H: 12 ft./3.65 m to concrete; Enterprise drop standard 8 ft. (2.4 m) to concrete across temperature (-20°C to 50°C) exceeding MIL-STD-810H Freezer version: 7 ft. (2.1 m) to concrete (-30°C to 50°C) exceeding MIL-STD810H |
| Tumble Specification | 6,000 3.3 ft. (1m) tumbles; meets or exceeds IEC tumble specification |
| Sealing | IP65 and IP68 with battery per applicable IEC sealing specifications |
| Vibration | 4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis |
| Electrostatic Discharge (ESD) | +/- 15 kV air discharge; +/- 8 kV direct discharge; +/- 8 kV indirect discharge |
Interactive Sensor Technology (IST)
| Light Sensor | Automatically adjusts display backlight brightness |
| Magnetometer | eCompass automatically detects direction and orientation |
| Motion Sensor | 3-axis accelerometer with MEMS Gyro |
Device Approvals, Certifications and Compliance
| TAA compliant; ARCore Google; Android Enterprise Recommended (AER) | |
| TAA (optional on select configurations) | Trade Agreement Act compliance optional on select configurations |
| Non-Incendive (NI); optional on select configurations | Class I,II, III Div 2; Gases: Class I, Groups A/B/C/D; Dusts: Class II, Groups F/G; Fibers/ Flyings: Class III; -20° C ≤ Ta ≥ 50° C T6 |
Data Capture
| Scanning |
SE58 1D/2D Extended Range Scan Engine with IntelliFocus™ technology with green laser aimer SE4770 1D/2D Scan Engine with red laser aimer |
| Camera | Front: 8 MP; Rear: 16 MP autofocus; flash LED generates balanced white light; supports Torch mode + HDR (standard) |
| NFC | ISO 14443 Type A and B; FeliCa and ISO 15693 cards |
Wireless WAN Data Communications (MC9450 only)
| Radio Frequency Band |
3G NA: B2/4/5; RoW: 1/2/4/5/8 4G NA: B2/4/5/7/8/12/13/14/17/25/26/29/30/38/41/ 48/66/71; RoW: B1/2/3/4/5/6/7/9/10/14/17/18/20/26/28/38/39/40/41/42/43/66/71 5G FR1 NA: n2/5/7/8/12/13/14/25/26/30/38/41/48/66/71/77/78; RoW: n1/2/3/5/7/8/12/18/20/26/28/38/40/41/66/71/77/78; Gigabit LTE-A; 5G NR Sub-6 (NSA, SA); LTE/NR Carrier Aggregation; supports private networking (LTE/5G) Note: Actual band support may vary by country or carrier, contact Zebra Tech Support for more details. |
| GPS | MC9450 only: GPS, GLONASS, Galileo, QZSS Dual-Band GNSS — Concurrent L1/G1/E1 (GPS/QZSS, GLO, GAL) + L5/E5a/BDSB2a (GPS/QZSS, GAL) a-GPS Supports XTRA |
| Multimedia | Wi-Fi Multimedia™ (WMM) and WMM-PS; Including TSPEC |
| VOIP Communications | Supports Workcloud CommunicationTM PTT Express and Workcloud Communication PTT Pro |
Wireless LAN
| Radio |
IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc; 2×2 MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6 GHz)2; Wi-Fi CERTIFIED 6™ (Wi-Fi 6E); Dual Band Simultaneous; IPv4, IPv6 |
| Data Rates | 2.4 GHz: 802.11b/g/n/ax — 20 MHz – up to 286.8 Mbps; 5 GHz: 802.11a/n/ac/ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz — up to 2402 Mbps; 6 GHz: 802.11ax — 20 MHz, 40 MHz, 80 MHz, 160MHz – up to 2402 Mbps |
| Fast Roam | 802.11r Fast BSS Transition; PMK Caching; Cisco CCKM; OKC |
| Operating Channels | Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 50, 52, 56, 60, 64, 100, 104, 108, 112, 114, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165; Channel 1-233 (5925-7125 MHz); Channel Bandwidth: 20, 40, 80, 160 MHz. Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency. |
| Security and Encryption | WEP (40 or 104 bit); Enhanced Open (OWE); WPA/WPA2 Personal (TKIP and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES); EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP256) – EAP-TLS; MC9450 only: EAP-SIM, EAP-AKA, EAP-AKA Prime |
| Certifications | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 (Wi-Fi 6E); WPA2-Personal; WPA2-Enterprise; WPA3-Personal WPA3-Enterprise (includes 192-bit mode); Protected Management Frames: Wi-Fi Enhanced Open; WMM (Wi-Fi Multimedia); WMM-Power Save WMM-Admission Control; Voice-Enterprise: Wi-Fi Direct; Wi-Fi Agile Multiband; Wi-Fi QoS Management; Wi-Fi Optimized Connectivity; Passpoint |
Wireless PAN
| Bluetooth | Class 2, Bluetooth v5.3 and Secondary BLE for beaconing within BLE battery |
Warranty
| Subject to terms of Zebra’s hardware warranty statement, the MC9400/MC9450 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement. |
Environmental Compliance
| RoHS Directive 2011/65/EU RoHS Amendment (EU) 2015/863 (EN IEC 63000:2018 Standard); For a complete list of product and materials compliance. |
Recommended Services
| Zebra OneCareTM Essential and Select support services; Zebra Visibility Services — VisibilityIQ™ Foresight. |
Footnotes
| 1. 5G vs. Wi-Fi 6: a Powerful Combination for Wireless; Intel; https://www.intel.com/content/www/us/en/wireless-network/5g-technology/5g-vs-wifi.html 2. Printing resolution, contrast and ambient light dependent 3. Requires the one-time purchase of a license for each OCR Wedge data type 4. Requires a Workcloud Communication license 5. Requires the purchase of the optional BLE battery and Device Tracker licenses 6. Available in North America 7. Requires one-time purchase of device licenses 8. GMS (Google Mobile Services) are not available on all models in all regions |
